- Details
-
Application
Application ■Processing ■Transferring ■Measuring required high precision
Feature
Repeatability 2μ
Stroke per jaw φ1mm
2 of Air connections at side.
Operating pressure and Gripping force
Specification
Description
NPC-4FS- Type
31 Repeatability (mm)
0.002 Number of jaws
3 Stroke per jaw (φmm)
1 Fixing hole circle
P.C.D89 Top fixing Bolt
M5×6 Bottom insertion dimension (mm)
(inside diameter×depth凸.凹）
φ75H7×3 Working fluid
Compressed Air
Pneumatic operating pressure (MPa)
0.15〜0.6 Body Material
Fe Weight
1860 Permissible revolutions (min-1)
- Gripping force (calculated Value) (N)
1192（at 0.1MPa）
Dimension
-
